APPLICATIONS
- For sewing light to medium weight fabrics, leather, canvas, vinyl, synthetics and various coated and laminated materials
- Suitable for stitching hollow, tubular and curved articles
- For stitching ornamental and functional two needle seams
- Designed for stitching such products as wearing apparel, shoes, boots, raincoats, foundation garments, luggage, handbags, travel-ware accessories, leather goods, etc.
- Also used for attaching vamps and back-straps or inserting counters on heavy shoes
FEATURES
- Vertical axis hooks
- Drop feed
- Safety clutch mechanism prevents the hooks from being damaged
- Reverse feed for back stitching, tacking and seam reinforcing
- Stitches per minute – 3000*
- Roller presser foot allows turning of sharp corners and tight curves
- Flat presser foot available
SPECIFICATIONS
Number of Needles | 2 (Double) |
Feeding Mechanism | Drop Feed |
Workspace | Standard Workspace |
Standard or Full Function | Standard Functions |
Speed, Max (S.P.M.) | 3000 |
Clearance Under Presser Foot | 15/64" (6mm) |
Stitch Length | 5 s.p.i. (5mm) |
Work Space | 1 7/8" x 3 1/2" (48mm x 85mm) |
Needle | with Roller Presser Foot DPXF22 or 134S with Flat Presser Foot 135 x 7 |
Bobbin | Metal 10656 Pre-wound G |
Bed Size | 7" x 20 3/8" (177mm x 518mm) |
Stitch Type | 301 |
Needle Bar Stroke | 1 1/4" (32mm) |
Hook | 12530 |
Post Height | 7" (178mm) |
Needle Gauges Available | with Roller Presser Foot 3/6" - 3/32" (1.2mm-2.4mm) with Flat Presser Foot 1/16" - 1/2" (1.5mm - 12.7mm) |
